Home » สกรูหลังคาเหล็ก » สกรูปลายสว่านยึดเหล็ก

สกรูปลายสว่านยึดเหล็ก

BDN Fasteners offer a full range of Australian AS3566 Standard self-drilling and self-tapping screws

for steel to steel and steel to timber applications in various coating options to cope with different environments.

We aim to provide customers with the highest quality product at a competitive price.

สกรูปลายสว่านยึดเหล็ก

Crest Fixing Fasteners

Crest Fixing Fasteners (Double Thread)

Carbon steel fasteners are ideal for fixing steel sheets onto steel substrates. Our crest fixing fasteners can penetrate a maximum of 6.0mm thick steel (#12 gauge). The thunder-shot point design of the TEK screw’s tips allows self-drilling on steel or any metal surface.

六角法蘭頭鑽尾螺絲(雙層牙)
六角法蘭頭鑽尾螺絲(雙層牙)
六角法蘭頭鑽尾螺絲(雙層牙) 01
六角法蘭頭鑽尾螺絲(雙層牙) 01
六角法蘭頭鑽尾螺絲(雙層牙) 02
六角法蘭頭鑽尾螺絲(雙層牙) 02

Crest Fixing Fasteners

Crest Fixing Fasteners (Full Thread)

Self-drilling screws (tek screw) for metal, steel manufactured by BDN Fasteners, which are carbon steel fasteners for fixing steel sheets onto steel substrates.

六角法蘭頭鑽尾螺絲(全牙)
六角法蘭頭鑽尾螺絲(全牙)
六角法蘭頭鑽尾螺絲(全牙)01
六角法蘭頭鑽尾螺絲(全牙)01
六角法蘭頭鑽尾螺絲(全牙)02
六角法蘭頭鑽尾螺絲(全牙)02

SELF DRILLING SCREWS FOR FIXING CLADDING TO METAL

Fixing Cladding to Metal

Fixing Cladding to Metal (#10 Gauge)

They are designed for valley fixing cladding profiles to steel purlins up to 4mm thick and timber battens.

  • 10-16 x 16mm
  • 10-16 x 19mm
  • 10-16 x 25mm
六角法蘭頭鑽尾螺絲#10
六角法蘭頭鑽尾螺絲#10
六角法蘭頭鑽尾螺絲#10 (2)
六角法蘭頭鑽尾螺絲#10 (2)
六角法蘭頭鑽尾螺絲#10 (3)
六角法蘭頭鑽尾螺絲#10 (3)

Fixing Cladding to Metal

Fixing Cladding to Metal (#12 Gauge)

Self drilling screws for metal Made from hardened C-1022 for better durability and strength, our valley fixing self-drilling metal screws are ideal for fixing wall curtains and cladding. The fixing’s steel purlins, which are up to 4.5mm thick, can support the weight of any roof deck. Other special features of our self-drilling metal roofing screws include flanged-head and EPDM washers.

  • 12-14 x 20mm
  • 12-14 x 25mm
  • 12-14 x 30mm
  • 12-14 x 35mm
六角法蘭頭鑽尾螺絲#12 (1)
六角法蘭頭鑽尾螺絲#12 (1)
六角法蘭頭鑽尾螺絲#12 (2)
六角法蘭頭鑽尾螺絲#12 (2)
六角法蘭頭鑽尾螺絲#12 (3)
六角法蘭頭鑽尾螺絲#12 (3)

SELF DRILLING SCREWS FOR STITCHING SCREWS FIXING TO METAL

Stitching Fasteners

Stitching Fasteners (Reduced Point)

ใช้ยึดแผ่นหลังคา 2 แผ่นเข้าด้วยกัน

Fix our self-drilling stitching screws onto panel to panel side lap or end lap of light gauge, lightweight steel. The screws come with reduced thunder-shot drilling point and to reduce thread stripping and our proprietary harpoon threads help retain pull-out strength.

  • 15-15 x 20mm (#15 Gauge)
六角法蘭頭鑽尾螺絲(金屬浪板縫合用)
六角法蘭頭鑽尾螺絲(金屬浪板縫合用)
六角法蘭頭束尾螺絲 (金屬浪板縫合用)
六角法蘭頭束尾螺絲 (金屬浪板縫合用)

Stitching Fasteners

Stitching Fasteners (Needle Point)

Attaches light gauge sheet metal to sheet metal.

  • 10-16 x 19mm (#10 Gauge)
六角法蘭頭尖尾螺絲 (輕型金屬浪板縫合用)
六角法蘭頭尖尾螺絲 (輕型金屬浪板縫合用)
六角法蘭頭尖尾螺絲 (輕型金屬浪板縫合用) 2
六角法蘭頭尖尾螺絲 (輕型金屬浪板縫合用) 2

สกรูปลายสว่านยึดหลังคาเมททัลชีท Point#5

Fixing to Thick Steel

Fixing to Thick Steel

Self drilling screws for steel, each fastener comes with patented thunder-shot drill points for steady and fast performance. These drill points are capable of drilling through 12.5mm thick steel while effectively clearing out swarf. Our valley fixing fasteners boast BN3 Silver Coating, which consists of multiple layers of specially-formulated chemicals that can easily withstand the elements.

六角法蘭頭鑽尾螺絲-五號尾 (重型金屬用)
六角法蘭頭鑽尾螺絲-五號尾 (重型金屬用)
六角法蘭頭鑽尾螺絲-五號尾 (重型金屬用) 2
六角法蘭頭鑽尾螺絲-五號尾 (重型金屬用) 2
六角法蘭頭鑽尾螺絲-五號尾 (重型金屬用) 3
六角法蘭頭鑽尾螺絲-五號尾 (重型金屬用) 3

SELF DRILLING SCREWS FOR CONCEALED FIXING TO METAL

Concealed Fixing Fasteners

Concealed Fixing Fasteners

The concealed fixing fastener’s wafer head is specifically designed to maintain a low profile upon fixing, creating an aesthetically pleasing flat surface without any protrusions which might create interference. Additionally, these types of fasteners come in PH2+ Philips drive and can penetrate steel thickness of up to 4.0mm.

  • 10-24 x 16mm
  • 10-24 x 22mm
十字威華頭鑽尾螺絲#10
十字威華頭鑽尾螺絲#10
十字威華頭鑽尾螺絲#10 (1)
十字威華頭鑽尾螺絲#10 (1)
BN3十字
BN3十字

SELF DRILLING SCREWS FOR TRUSS TO PLATE CONNECTION

Truss to Plate Connection

Truss to Plate Connection

BDN’s METAL-Tite trust-to-plate connection fasteners are designed for fixing steel trusses to steel plates or beams of thicknesses ranging from 0.75mm to 1.6mm. Our truss to metal fasteners also follows Australian AS3566 standards and come with high pull-out strength and patented trident drill points.

  • 12-14 x 20mm
六角法蘭頭鑽尾螺絲 (輕鋼架螺絲)
六角法蘭頭鑽尾螺絲 (輕鋼架螺絲)
六角法蘭頭鑽尾螺絲 (輕鋼架螺絲) 2
六角法蘭頭鑽尾螺絲 (輕鋼架螺絲) 2
六角法蘭頭鑽尾螺絲 (輕鋼架螺絲) 3
六角法蘭頭鑽尾螺絲 (輕鋼架螺絲) 3

SELF DRILLING SCREWS FOR TRUSS TO PLATE CONNECTION

Frame Fixing Screws

Frame Fixing Screws

Flat top frame screw is designed for stud to plate connections and connection lintels to plate without pre-punched holes.

  • M6.0-1.00 x 22mm
十字平頭鑽尾螺絲(金屬框架螺絲)
十字平頭鑽尾螺絲(金屬框架螺絲)
十字平頭鑽尾螺絲(金屬框架螺絲) 2
十字平頭鑽尾螺絲(金屬框架螺絲) 2
十字平頭鑽尾螺絲(金屬框架螺絲) 3
十字平頭鑽尾螺絲(金屬框架螺絲) 3

All BDN Fasteners undergo stringent in-house quality control to guarantee fast and stable drilling performance, and are regularly tested by accredited 3rd party laboratories for independent and impartial certification.

BDN Fasteners_QC_10
BDN Fasteners_QC_10
BDN Fasteners_QC_02
BDN Fasteners_QC_02
BDN Fasteners_QC_04
BDN Fasteners_QC_04
BDN Fasteners_QC
BDN Fasteners_QC
